High Performance and Super Computing

Supercomputer_Lawrence_Livermore_National_Lab_1
(Supercomputer, Lawrence Livermore National Laboratory)


- High-Performance Computing (HPC)

High Performance Computing (HPC) most generally refers to the practice of aggregating computing power in a way that delivers much higher performance than one could get out of a typical desktop computer or workstation in order to solve large problems in science, engineering, or business. It is the use of parallel processing and supercomputers to run advanced and complex application programs. The system focuses on developing parallel processing systems by integrating both administration and computational methods.

And for decades, HPC and supercomputing were intrinsically linked. Specialized computing resources were necessary to help researchers and scientists extracts insights from massive data sets. Scientist need HPC because they hit a tipping point. At some point in research, there is a need to:

  • Expand the current study area (regional → national → global)
  • Integrate new data
  • Increase model resolution



But … processing on my desktop or a single server no longer works. Some typical computational barriers:

  • Time – processing on local systems is too slow or not feasible
  • CPU Capacity -- Can only run one model at a time
  • Develop, implement, and disseminate state-of-the-art techniques and tools so that models are more effectively applied to today’s decision-making
  • Management of Computer Systems – Science Groups don’t want to purchase and manage local computer systems – they want to focus on science



- Three Key Components of HPC Solutions

There are three key components of high-performance computing solutions: compute, network, and storage. Supercomputing is a form of high-performance computing that determines or calculates using a powerful computer, a supercomputer, reducing overall time to solution. Supercomputers are made up of interconnects, I/O systems, memory and processor cores.

In order to develop a HPC architecture, multiple computer servers are networked together to form a cluster. Algorithms and software programs are executed concurrently on the servers in the cluster. To get the results, the cluster is networked to data storage. These modules function together to complete different tasks. To achieve maximum efficiency, each module must keep pace with others, else the performance of the entire HPC infrastructure would deteriorate.

HPC is the aggregation of computing power. This is the functional premise of HPC solutions: "the aggregation of multiple compute resources into an interconnected whole capable of tackling bigger problems in smaller amounts of time." While all computing power is somewhat aggregated. HPC is the aggregation of many different computers and systems to tackle one problem.

HPC is undergoing a period of rapid evolution involving changes in computational architectures and the types of problems that are being attacked. Aside from the traditional types of “hard” computational problems, there is now considerably more emphasis on “system-scale” simulation, data-intensive problems, and large-scale artificial intelligence/machine learning applications.



- HPC Clusters

Generally speaking, HPC is the use of large and powerful computers designed to efficiently handle mathematically intensive tasks. Although HPC "supercomputers" exist, such systems often elude the reach of all but the largest enterprises.

Instead, most businesses implement HPC as a group of relatively inexpensive, tightly integrated computers or nodes configured to operate in a cluster. Such clusters use a distributed processing software framework -- such as Hadoop and MapReduce -- to tackle complex computing problems by dividing and distributing computing tasks across several networked computers. Each computer within the cluster works on its own part of the problem or data set, which the software framework then reintegrates to provide a complete solution.



The Great Wall Of China_011221A
[The Great Wall Of China - Civil Engineering Discoveries]

- Accessing Software on HPC Systems

HPC is the ability to process data and perform complex calculations at high speeds. To put it into perspective, a laptop or desktop with a 3 GHz processor can perform around 3 billion calculations per second. While that is much faster than any human can achieve, it pales in comparison to HPC solutions that can perform quadrillions of calculations per second.

One of the best-known types of HPC solutions is the supercomputer. A supercomputer contains thousands of compute nodes that work together to complete one or more tasks. This is called parallel processing. It’s similar to having thousands of PCs networked together, combining compute power to complete tasks faster.

As HPC systems are being used by many users with different requirements, they usually have multiple versions of frequently used software packages installed. As it is not easy to install and use many versions of a package at the same time, this system uses environment modules that allow users to configure the software environment with the specific version required.



- Supercomputer Infrastructure

Unlike traditional computers, supercomputers use more than one central processing unit (CPU). These CPUs are grouped into compute nodes, comprising a processor or a group of processors - symmetric multiprocessing (SMP) - and a memory block. At scale, a supercomputer can contain tens of thousands of nodes. With interconnect communication capabilities, these nodes can collaborate on solving a specific problem. Nodes also use interconnects to communicate with I/O systems, like data storage and networking. A matter to note, because of modern supercomputers' power consumption, data centers require cooling systems and suitable facilities to house it all.

The use of several CPUs to achieve high computational rates is necessitated by the physical limits of circuit technology. Electronic signals cannot travel faster than the speed of light, which thus constitutes a fundamental speed limit for signal transmission and circuit switching. This limit has almost been reached, owing to miniaturization of circuit components, dramatic reduction in the length of wires connecting circuit boards, and innovation in cooling techniques (e.g., in various supercomputer systems, processor and memory circuits are immersed in a cryogenic fluid to achieve the low temperatures at which they operate fastest).

Rapid retrieval of stored data and instructions is required to support the extremely high computational speed of CPUs. Therefore, most supercomputers have a very large storage capacity, as well as a very fast input/output capability.



- Supercomputers and AI

Although supercomputers have long been a necessity in fields such as physics and space science, the expanded use of artificial intelligence and machine learning has prompted a surge in demand for supercomputers capable of performing a quadrillion computations per second. In reality, the very next generation of supercomputers, known as exascale supercomputers, is enhancing efficiency in these areas.

Supercomputers, or, to put it another way, machines with accelerated hardware, are worthy of improving the velocity of the artificial intelligence system. It can train quicker, on larger, more detailed sets, along with more oriented and deeper training sets, thanks to its improved pace and ability.



- Supercomputers and Software Defined Networking

Supercomputers have long been characterized by their closed and proprietary interconnects. Software Defined Networking (SDN) allows for the programmatic flow management of network traffic.

The introduction of SDN into the High Performance Computing (HPC) world permits scientists to leverage a high speed and simplified model for access to the immense computing power of supercomputers. As increasingly larger experimental and observational sites come online, scientists have a need to not only store data, but to compute upon that data in near real-time. SDN provides an avenue for the data from these experiments to flow directly into the supercomputer, without having to be staged first at an intermediary site, thus reducing the time to computation for that data. The newly gleaned results can then be used to guide the experiments in near real-time, allowing for more accurate data.





[More to come ...]
